GJS(04)-3

Application:

The product can be applied in the straight line and branch line（one into two, one into three）connections of optical cables within the diameter of 22mm(φ), all types and structures, when laid overhead ,in the pipeline, underground or in the well. Meanwhile, it is also applied to the connection of all-plastic city phone cables.

Structural features:

1. All property indexes are in accordance with National Standard;

2. The case body is made of high-intensity engineering plastics with ess weight, high mechanical intensity, corrosive-resistance, anti-thunder struck and long service life;

3. The case body and cable entrance are sealed with adhesive rubber strip(non-vulcanized) and sealed tape. It can be re-opened and easy to maintain;

4. Unique disposition of 4 different cable loops(φ12.5，φ17，φ20，φ22) enables user to choose different outer diameter according to actual cables, which enhances the reliability of the cable entrance sealing;

5. Overlapping fiber-melting tray and separate insulation earth unit make the disposition of the fibers, expanding the capacity and cable-earthen flexible and safe;

6. Outer metal component and fixing unit are made of stainless steel.

Specification:

Model No.	GJS(04)-3
Dimensions (mm)	435190120
Weight（Kg）	2.6
Cable inlet/outlet	2/2
Cable diameter(mm)	Φ10~Φ22
Tray capacity （core）＆ QTY	24 (single core) ＆ 8pcs
Max splice capacity （core）	192 (single core)
Sealing type	Unvulcanized rubber
